Character Recognition on PCB Components AI

Add a real-time OCR layer to every character on every PCB component on the SMT line with Vision AI for character recognition on PCB components. Roboflow reads datecodes, lot codes, part numbers, and pin-1 markings on ICs, passives, and connectors, catches AS6081 counterfeit-suspect components, and feeds the results into your MES via IPC-CFX and pick-and-place PLCs via IPC-HERMES-9852.

Datecode, Lot Code, and Part-Number Reading:

• Read datecodes and lot codes on IC package tops (BGA, QFN, LGA, WLCSP, μBGA, SOIC, QFP, DIP, PLCC) with sub-pixel accuracy on laser-marked characters from 0.15mm on μBGA up to 2-3mm on power ICs, on matte-black epoxy, ceramic, matte-plastic, and metal-lidded tops
• Read part numbers and orientation dots on polarized components (aluminum electrolytic, tantalum, polymer capacitors, LEDs, diodes) plus lot codes on chip resistors and capacitors (0201, 01005, 0402, 0603, 0805, 1206) and marks on RF modules and shielded components
• Read connector part numbers and pin-1 markings on fine-pitch board-to-board, board-to-cable, and RF connectors (SMA, MMCX, coax)

Counterfeit Detection, Part Verification, and Wrong-Component Catch:

• Detect AS6081 counterfeit-suspect components at incoming inspection and post-placement AOI: mismatched laser-mark geometry, refurbished-part indicators (blacktop paint, sanded tops, mismatched pin-1), lot-code sequence anomalies, and OCR-vs-package-family mismatch
• Catch part-number substitutions: wrong component in the right slot, right component in the wrong slot, and taped-reel mix-ups at post-placement AOI before reflow commits
• Support IPC-A-610 Class 1, 2, and 3 acceptability with per-class OCR confidence thresholds and produce IPC-1782 traceability tying every character to board, panel, feeder, reel, and vendor-lot

Pre-Reflow, Post-Reflow, X-Ray, ICT Coverage, and MES Integration:

• Deploy at every AOI stage: pre-reflow, post-reflow, 3D AOI, 2D and 3D X-ray, ICT, functional test, pick-and-place head cameras, incoming inspection, hand-inspection microscopes, and RMA return stations
• Integrate with MES (Cogiscan CoNECT, Aegis FactoryLogix, Valor MSS, iTAC, Critical Manufacturing) via IPC-CFX, with pick-and-place PLCs via IPC-HERMES-9852, and with ERP (SAP, Oracle) for full IPC-1782 lot genealogy
• Log every read with confidence, image, character segmentation, reference designator, package family, mark method, counterfeit-suspect flag, timestamp, board, panel, feeder, reel, and vendor lot for IPC-A-610, IPC-1782, IATF 16949, AS9100/AS6081, MIL-STD-883, and FDA Part 820 records

Bring intelligence to every character today.

‍

More About Character Recognition on PCB Components

Does character recognition on PCB components support IPC-A-610, IPC-1782, AS6081, IATF 16949, and FDA 21 CFR Part 820?

Yes. Roboflow supports SMT lines operating under IPC-A-610 (Class 1, 2, and 3), IPC-J-STD-001, IPC-7351, IPC-1782, IPC-CFX, IPC-HERMES-9852, IEC 61340, IATF 16949, AEC-Q100/Q101/Q200, AS9100 and AS6081 counterfeit avoidance, MIL-STD-883, MIL-PRF-31032/38534/38535/19500, FDA 21 CFR Part 820 and Part 11, ISO 13485, and ITAR/EAR. Every read is logged with confidence, image, character segmentation, reference designator, package family, mark method, counterfeit-suspect flag, board, panel, feeder, reel, and vendor lot, ready for IPC-A-610 records, IPC-1782 genealogy, automotive audits, aerospace and defense qualification, FDA DHR evidence, and PPAP submissions.
